-- VOLT TECNOLOGIA MIB ESPECIFICATION
--
VOLT-MIB DEFINITIONS ::= BEGIN
IMPORTS
MODULE-IDENTITY,enterprises,
IpAddress ,Integer32 FROM SNMPv2-SMI
-- Gauge, TimeTicks FROM RFC1155-SMI
DisplayString FROM SNMPv2-TC
OBJECT-TYPE FROM RFC-1212
NOTIFICATION-TYPE FROM SNMPv2-SMI
-- TRAP-TYPE FROM RFC-1215
SnmpSecurityModel,
SnmpMessageProcessingModel,
SnmpSecurityLevel,
SnmpAdminString FROM SNMP-FRAMEWORK-MIB
KeyChange FROM SNMP-USER-BASED-SM-MIB
TEXTUAL-CONVENTION FROM SNMPv2-TC
MODULE-COMPLIANCE, OBJECT-GROUP ,
NOTIFICATION-GROUP FROM SNMPv2-CONF;
voltInfo MODULE-IDENTITY
LAST-UPDATED "201704070827Z"
ORGANIZATION "Volt Tecnologia"
CONTACT-INFO
"www.volt.ind.br"
DESCRIPTION
"Arquivo MIB Pop Protect SNMP."
REVISION "201704070827Z"
DESCRIPTION
"Creation Date"
::= { volt 1 }
volt OBJECT IDENTIFIER ::= { enterprises 17095 }
product OBJECT IDENTIFIER ::= { voltInfo 1 }
setup OBJECT IDENTIFIER ::= { voltInfo 2 }
control OBJECT IDENTIFIER ::= { voltInfo 3 }
snmpUsm OBJECT IDENTIFIER ::= { voltInfo 4 }
snmpTrap OBJECT IDENTIFIER ::= { voltInfo 5 }
snmpv3PvtObject OBJECT IDENTIFIER ::= { voltInfo 6 }
trapNotifications OBJECT IDENTIFIER ::= { voltInfo 0 }
mchipMIBConformance OBJECT IDENTIFIER ::= { voltInfo 8 }
mchipMIBCompliances OBJECT IDENTIFIER ::= { mchipMIBConformance 1 }
mchipMIBGroups OBJECT IDENTIFIER ::= { mchipMIBConformance 2 }
-- ON-OFF ::= INTEGER { ON(1), OFF(0) }
MCHPUsmAuthPrivProtocol ::= TEXTUAL-CONVENTION
STATUS current
DESCRIPTION
"This textual convention enumerates the authentication and privledge
protocol for USM configuration.
"
SYNTAX INTEGER
{
noAuthProtocol(1),
hmacMD5Auth(2),
hmacSHAAuth(3),
noPrivProtocol(4),
desPrivProtocol(5),
aesPrivProtocol(6)
}
name OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Pop Protect SNMP"
::= { product 1 }
version OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Versao Hardware 1.0.1"
::= { product 2 }
date OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Data de Criacao"
::= { product 3 }
statusalarme OBJECT-TYPE
SYNTAX INTEGER (0..1)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status do Alarme"
::= { control 8 }
temperatura OBJECT-TYPE
SYNTAX INTEGER (0..125)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Temperatura Interna"
::= { control 9 }
sensortemperatura OBJECT-TYPE
SYNTAX INTEGER (0..125)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Sensor de Temperatura Externo"
::= { control 10 }
voltagementrada OBJECT-TYPE
SYNTAX INTEGER (0..250)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Voltagem da Entrada AC"
::= { control 11 }
voltagembateria OBJECT-TYPE
SYNTAX INTEGER (0..400)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Voltagem da Bateria"
::= { control 12 }
statusac OBJECT-TYPE
SYNTAX INTEGER (0..1)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status da Rede Eletrica"
::= { control 13 }
statussensor1 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status do Sensor 1"
::= { control 14 }
statussensor2 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status do Sensor 2"
::= { control 15 }
statussensor3 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status do Sensor 3"
::= { control 16 }
contadorsensor1 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Contador do Sensor 1"
::= { control 17 }
contadorsensor2 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Contador do Sensor 2"
::= { control 18 }
contadorsensor3 OBJECT-TYPE
SYNTAX INTEGER (0..5)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Contador do Sensor 3"
::= { control 19 }
statusrele OBJECT-TYPE
SYNTAX INTEGER (0..1)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status de Acionamento do Rele"
::= { control 20 }
statussirene OBJECT-TYPE
SYNTAX INTEGER (0..1)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Status de Acionamento da Sirene"
::= { control 21 }
trapTable OBJECT-TYPE
SYNTAX SEQUENCE OF TrapEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Trap table"
::= { setup 1 }
trapEntry OBJECT-TYPE
SYNTAX TrapEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Single trap entry containing trap receiver info."
INDEX { trapReceiverNumber }
::= { trapTable 1 }
TrapEntry ::=
SEQUENCE {
trapReceiverNumber
Integer32,
trapEnabled
Integer32,
trapReceiverIPAddress
IpAddress,
trapCommunity
DisplayString
}
trapReceiverNumber OBJECT-TYPE
SYNTAX Integer32(0.. 4)
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Index of trap receiver"
::= { trapEntry 1 }
trapEnabled OBJECT-TYPE
SYNTAX INTEGER { no(0),yes(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Indicates if this trap entry is enabled or not."
::= { trapEntry 2 }
trapReceiverIPAddress OBJECT-TYPE
SYNTAX IpAddress
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Trap receiver IP address"
::= { trapEntry 3 }
trapCommunity OBJECT-TYPE
SYNTAX DisplayString (SIZE (0..7))
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Trap community to be used by agent to send trap"
::= { trapEntry 4 }
mchpUsmUserTable OBJECT-TYPE
SYNTAX SEQUENCE OF MchpUsmUserEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION "This table is used to get the SNMPv3 access, user need to configure security
name,authentication,auth password,priv protocol and priv
password.
"
::= { snmpUsm 1 }
mchpUsmUserEntry OBJECT-TYPE
SYNTAX MchpUsmUserEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION "User security configurations for USM.
"
INDEX { usmIndex }
::= { mchpUsmUserTable 1 }
MchpUsmUserEntry ::= SEQUENCE {
usmIndex Integer32,
usmSecurityName SnmpAdminString,
usmAuthProtocol MCHPUsmAuthPrivProtocol,
usmAuthKey KeyChange,
usmPrivProtocol MCHPUsmAuthPrivProtocol,
usmPrivKey KeyChange
}
usmIndex OBJECT-TYPE
SYNTAX Integer32 (1..3)
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION "Usm configuration index. "
::= { mchpUsmUserEntry 1 }
usmSecurityName OBJECT-TYPE
SYNTAX SnmpAdminString
MAX-ACCESS read-write
STATUS current
DESCRIPTION "A human readable string representing the user in
Security Model independent format.
The default transformation of the User-based Security
Model dependent security ID to the securityName and
vice versa is the identity function so that the
securityName is the same as the userName.
"
::= { mchpUsmUserEntry 2 }
usmAuthProtocol OBJECT-TYPE
SYNTAX MCHPUsmAuthPrivProtocol
MAX-ACCESS read-write
STATUS current
DESCRIPTION "Authentication support to the SNMPv3.
If usmAuthProtocol == NoAuthProtocol, then SNMPv3 Stack does
not support/requires authentication.
If usmAuthProtocol == HMACMD5Auth , supports MD5 auth
If usmAuthProtocol == HMACSHAAuth, supports SHA Auth
If a set operation tries to set value as
NoAuthProtocol while the usmPrivProtocol value
for the same userName is not equal to NoPrivProtocol,
then an 'inconsistentValue' error must be returned.
This implies that SNMP command generator (SNMP Manager)
application must first ensure that the usmPrivProtocol is set
to NoPrivProtocol value before it can set
the usmAuthProtocol value to NoAuthProtocol.
"
::= { mchpUsmUserEntry 3 }
usmAuthKey OBJECT-TYPE
SYNTAX KeyChange -- typically (SIZE (0 | 32)) for HMACMD5
-- typically (SIZE (0 | 40)) for HMACSHA
MAX-ACCESS read-write
STATUS current
DESCRIPTION "This object in the MIB is associated to usmAuthProtocol.
A secret authentication key is required to establish a secure connection
between snmp agent and manager.
"
::= { mchpUsmUserEntry 4 }
usmPrivProtocol OBJECT-TYPE
SYNTAX MCHPUsmAuthPrivProtocol
MAX-ACCESS read-write
STATUS current
DESCRIPTION " A privacy protocol to provide encryption and decryption
of SNMPv3 pdu.
"
::= { mchpUsmUserEntry 5 }
usmPrivKey OBJECT-TYPE
SYNTAX KeyChange -- typically (SIZE (0 | 32)) for DES
MAX-ACCESS read-write
STATUS current
DESCRIPTION "This object in the MIB is associated to usmPrivProtocol.
A secret privacy key is required to establish a secure connection
between snmp agent and manager.
"
::= { mchpUsmUserEntry 6 }
-- Target MIB
mchpTargetTable OBJECT-TYPE
SYNTAX SEQUENCE OF MchpTargetEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A table for SNMP target information. This information is required for
generation of SNMP trap notifications."
::= { snmpTrap 1 }
mchpTargetEntry OBJECT-TYPE
SYNTAX MchpTargetEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A set of SNMP target information.
"
INDEX { snmpTargetIndex }
::= { mchpTargetTable 1 }
MchpTargetEntry ::= SEQUENCE {
snmpTargetIndex Integer32,
snmpTargetMPModel SnmpMessageProcessingModel,
snmpTargetSecurityModel SnmpSecurityModel,
snmpTargetSecurityName SnmpAdminString,
snmpTargetSecurityLevel SnmpSecurityLevel
}
snmpTargetIndex OBJECT-TYPE
SYNTAX Integer32(1..8)
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"The locally arbitrary, but unique identifier associated
with mchpTargetEntry."
::= { mchpTargetEntry 1 }
snmpTargetMPModel OBJECT-TYPE
SYNTAX SnmpMessageProcessingModel
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Message Processing Model to be used when generating/processing
SNMP messages using this entry."
::= { mchpTargetEntry 2 }
snmpTargetSecurityModel OBJECT-TYPE
SYNTAX SnmpSecurityModel (1..2147483647)
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Security Model to be used while generating SNMP
messages using this entry. An implementation may
choose to return an inconsistentValue error if an
attempt is made to set this variable to a value
for a security model which the implementation does
not support."
::= { mchpTargetEntry 3 }
snmpTargetSecurityName OBJECT-TYPE
SYNTAX SnmpAdminString
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The securityName which identifies the Principal on
whose behalf SNMP messages will be generated.
"
::= { mchpTargetEntry 4 }
snmpTargetSecurityLevel OBJECT-TYPE
SYNTAX SnmpSecurityLevel
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Level of Security to be used when generating
SNMP messages using this entry."
::= { mchpTargetEntry 5 }
snmp-demo-trap NOTIFICATION-TYPE
OBJECTS { trapCommunity}
STATUS current
DESCRIPTION
"SMIV2 Trap notification information for the SNMP Manager.
The objects used in the demo trap notification are
analogPot0,pushButton,ledD5 and trapCommunity. User should modify this object
information as per the requirements. These object should
have been defined as part of the MIB.
"
::= {trapNotifications 1}
mchipDemoCompliance1 MODULE-COMPLIANCE
STATUS current
DESCRIPTION
"This group is for SNMP demo applications."
MODULE -- this module
MANDATORY-GROUPS { mchipDemoGroup1, mchipDemoGroup2}
::= { mchipMIBCompliances 1 }
mchipDemoCompliance2 MODULE-COMPLIANCE
STATUS current
DESCRIPTION
"This group is for trap demo applications."
MODULE -- this module
MANDATORY-GROUPS {mchipDemoGroup3}
::= { mchipMIBCompliances 2 }
mchipDemoGroup1 OBJECT-GROUP
OBJECTS { name,version,date,statusalarme,temperatura,sensortemperatura,voltagementrada,voltagembateria,statusac,statussensor1,
statussensor2,statussensor3,contadorsensor1,contadorsensor2,contadorsensor3,statusrele,statussirene,
trapEnabled,trapReceiverIPAddress,trapCommunity}
STATUS current
DESCRIPTION
"A collection of objects providing basic product
and control of a product."
::= { mchipMIBGroups 1 }
mchipDemoGroup2 OBJECT-GROUP
OBJECTS { usmSecurityName,usmAuthProtocol,usmAuthKey,
usmPrivProtocol,usmPrivKey,snmpTargetMPModel,
snmpTargetSecurityModel,snmpTargetSecurityName,
snmpTargetSecurityLevel}
STATUS current
DESCRIPTION
"A collection of objects are used for SNMPV3 Configuration."
::= { mchipMIBGroups 2 }
mchipDemoGroup3 NOTIFICATION-GROUP
NOTIFICATIONS {snmp-demo-trap}
STATUS current
DESCRIPTION
"SNMP Trap Notification object."
::= { mchipMIBGroups 3 }
END
